Luxaflex 32mm Room Darkening Duette Blind

Inside Recess

The recess is inside the window opening. Choose this option if you want to the blind to lie in the recess of the window.

Width: Measure the inside width of the window at the top middle and bottom. Use the narrowest width measurement always using a metal tape measure.

Height: Measure the height of the window at the left, centre and right. Use the shortest height measurement always using a metal tape measure.

We will deduct the manufacturers recommended tolerance off the width/drop of the blind to ensure the blind operates perfectly within the window recess.

Outside Recess/Exact

Outside Recess/Exact is the outside of the window opening, overlapping the window recess. Choose this option if you want the blind to overlap the window recess.

Width
To minimise light leakage it's recommended that the blind overlaps the window recess on the width by least 40mm each side (60mm in the case of vertical blinds).

Height
When measuring the height take into account the required space for the mounting bracket. A flat surface of a minimum 70mm above is required (50mm in the case of vertical blinds). The overlap at the bottom of the blind is a matter of personal choice but please take into account obstacles such as radiators.

If you are unsure please contact us on 01949 845399

Luxaflex® Duette®/Plisse Blind Models

OTHER MODELS AVAILABLE ON REQUEST - 01949 845399

Standard Stack - This is the standard model that has a fixed headrail at the top for top stacking.

Available with ALL control options.

Top Down, Bottom Up - This model has a fixed head rail although the fabric is not fixed to it. The fabric has top and bottom rails fixed to it. There are visible tension wires when the blind is stacked at the bottom.

Available with control options Cord & Cord Lock, Smartcord & Literise ( There will be controls on both side of the blind)

Model 3242 - This model has no fixed rails and works by means of side tension wires, therefore you will need to fit mounting plates in all 4 corners. (see size restrictions below) Hand Control ONLY

Min Width 300mm - Max Width 1700mm - Min Drop 100mm - Max Drop 2300mm (Blinds over 1280mm with be supplied with two handles)

Mounting Plate Dimensions - 20mm x 15mm x 5mm

If you are unsure please call us on 01949 845399

Luxaflex® Duette/Plisse® Blind Control Options

Cord and Cord Lock

This option has lift cord with cord lock system.

Hand Control

Hand or Wand control with tensioned cord system with fixing plates and standard handle (max width 1500mm) Same handle as the LiteRise option

SmartCord

Retractable cord operation, meaning the cord remains a constant distance from the floor whilst not in operation.

LiteRise

Operated by a stylish handle, Literise has no operating cords making it completely child safe.

Optional wand handle and wand available - see below images

Hand Operation Wand Operation

Chain

Chain operation supplied with a child safe breakaway device

Motorisation Available on Request

If you are unsure please call us on 01949 845399

Luxaflex® Duette®/Plisse Profile & Hardware Colour

The head rail and bottom rail are colour co-ordinated. There are a total of 6 hardware colours.

Of course you can select one of the other colours to suit your window frame and/or interior.

HEAD RAIL - DIMENSIONS

Contact us on 01949 845399 if you want to know which colour Luxaflex® co-ordinate with any selected fabric.

Luxaflex® Duette® LightLock^TM

Duette® Shades with LightLock^TM feature a unique side channel in a black reflective tone that overlaps the front of the shade. When combined with the Room Darkening range, this absorbs or deflects nearly all the incoming light seeping into the room. Fitting securely into the window frame, Duette® Shades with LightLock^TM is the only Duette® Shade product that offers this level of room darkening.

NOTE: LightLock^TM is only available with standard Cord control or Tensioned Hand control

Without LightLock

With LightLock

• L-profiles are pre-drilled
• Available in 6 colours
• End caps are extendable by 3mm for an exact fit in height
• Anti-reflective black interior to significantly reduce incident light
• Dimensions of LightLock profiles - approximately 25mm x 25mm

Luxaflex® Duette/Plisse® Blind Telescopic Wand

If you choose Hand/Wand control you can also choose to purchase a 3m telescopic wand to aid the opening and closing of your blind if it is high up or out of reach.

Rod colour may change colour displayed is for illustration purposes only.

If you are unsure please call us on 01949 845399

Blind Installation Heights

The 2014 changes to the child safety requirements of BS EN 13120:2009+A12014 place an obligation on all blind manufacturers to sell compliant products.

If you do not know the installation height of the blind please enter 00 in the box and your blind will be manufactured in accordance with the Safety Regulation requirements.

If you input an installation height (this is the height the mounting brackets will be installed above the floor level) then your blind may be manufactured with longer controls providing they confirm to the child safety legislation.

For windows in unusual positions or installed extremely high, please contact us.

If you are unsure please contact us on 01949 845399

Luxaflex® Duette®/Plisse Blind Models

T1 Side Guiding with fixed bottom rail

T2 Side Guiding with fixing plates
