Vale Allusion Blind

Place your mouse over this image

On offer

22%OFF

  • 1 Year Guarantee
  • Info
  • Installation Instructions (3)
  • Delivery

Standard Specification:

  • Slimline Vogue Head Rail - White
  • Wand Operation on Left or Right (when blind is open)
  • Top Fix Brackets
  • Left or Right Stack/Bunch

Alternate Specification:

  • Slimline Vogue Head Rail - Anthracite Grey or Black
  • Cord and Chain Operation on Left or Right - Length determined by Child Safety Legislation
  • Side Fix and Extension Brackets
  • Allusion Fascia Head Rail in White, Anthracite Grey or Black
  • Battery Tilt Only Operation
  • Mains Powered Tilt and Open - Head Rail changes to the Benthin version and is available in white only

NOTE: Split Bunch/Stack is available but not recommended as the blind cannot meet in the middle

Min Width - 600mm   Max Width - 5000mm

Min Drop - 600mm    Max Drop - 4300mm

Delivery

For full details of our delivery times please
click here

Beat a Price

Vale Allusion Blind

Vista Nordic FR

Order Code
10013
£85.16
£66.43

Vale Allusions Blinds offer the ultimate in shading flexibility and privacy. Made with a stunning combination of sheer and opaque textured fabric Allusion Blinds look stunning on larger windows, bi-folding and patio doors.

Cleverly combining the delicacy of a voile fabric with the versatility of rotation vertical vanes, Allusion offers a number of light and privacy options.

Battery Tilt Only operation and Mains Powered Tilt and Open operation available

Price in GBP
£85.16
£66.43
    • *
    • *
    • sa_btn_ten_10158080
    Click for help
    Click for Help
    Click for Help
    Click for Help
    Click for Help
    Click for Help
    Click for help
    4 characters remaining.
    Click for Help

    Inside Recess


    The recess is inside the window opening. Choose this option if you want to the blind to lie in the recess of the window.

    Width: Measure the inside width of the window at the top middle and bottom. Use the narrowest width measurement always using a metal tape measure.

    Height: Measure the height of the window at the left, centre and right. Use the shortest height measurement always using a metal tape measure.

    We will deduct the manufacturers recommended tolerance off the width/drop of the blind to ensure the blind operates perfectly within the window recess.



    Outside Recess/Exact


    Outside Recess/Exact is the outside of the window opening, overlapping the window recess. Choose this option if you want the blind to overlap the window recess.

    Width
    To minimise light leakage it's recommended that the blind overlaps the window recess on the width by least 40mm each side (60mm in the case of vertical blinds).

    Height
    When measuring the height take into account the required space for the mounting bracket. A flat surface of a minimum 70mm above is required (50mm in the case of vertical blinds). The overlap at the bottom of the blind is a matter of personal choice but please take into account obstacles such as radiators.



    If you are unsure please contact us on 01949 845399

    VALE Allusion Blinds come complete with a slimline Vogue head rail in Ice White as standard. Alternatively you can select Anthracite Grey or Piano Black.

    Allusion Ice White Head Rail Vogue Head Rail

    NOTE: Please be aware that the headrail shape and size will change if you select mains powered. This Benthin headrail is only available in White.

    Battery operation is tilt only

    Main operation is tilt and draw

    Benthin Headrail 1 Benthin Headrail 2

    The Benthin headrail dimensions are 40mm Deep x 25mm High

    Battery pack dimensions are 350mm long x 55mm deep

    Main Headrail is approximately 95mm Deep including motor x 25mm High

    Alternatively you can select the the Allusion Fascia headrail in either White, Anthracite Grey or Black.

    Allusion Fascia Piano Black Allusion Fascia

    VALE Allusion Blinds come complete with wand operation which allows you to open the blind fully and also twist the vanes.

    The wand will be at the end of the fabric to allow you to pull the louvres accross the window. See image below

    Allusion Wand Control

    Alternatively you can select to have the operation via a cord and chain on either the left or the right.

    VALE Allusion Blinds are also available with Tilt Only rechargeable battery operation. This means you will be able to rotate the vanes from the comfort of your armchair. (This will only rotate the vanes it will not fully open the blind) You will still have the wand on the blind to allow you to fully open the vanes. (The wand can also still rotate the vanes)

    Battery size 350mm long x 55mm deep

    If you select the Mains Operation you can rotate the vanes and also fully open or close the blind to the chosen stack point.

    Remote Control Handsets

    If purchasing a manual blind please select 'Not Required' to this option.

    If you have more than one blind on your order you need only select the required remote control on one blind.

    Situo 1 VAR RTS

    Situo 1 Variation RTS II Pure

    • Single Channel Remote
    • The control wheel offers greater precision when tilting the slats of the blind
    • Can have upto 8 items operating in unison on the single channel
    Situo 5 VAR RTS

    Situo 5 Variation RTS II Pure

    • Multi Channel Remote
    • 4 Single channels and 1 Multi channel function
    • Offers the ability to operate multiple blinds independently from 1 remote
    • Each channel can have upto 8 items operating in unison
    Smoove 1 RTS Wall Switch Pure

     Smoove 1 RTS Wall Switch Pure

    • Secure, single channel RTS (operates one blind or group of blinds simultaneously)
    • Battery powered control unit that can be placed anywhere within range

    If you are unsure please contact us on 01949 845399

    VALE Allusion Blinds come complete with top fix spring brackets.

    Allusion Top Fix Spring Brackets

    Allusion Top Fix Spring Brackets Size

    Alternatively you can select face fix brackets for a Shallow Frame

    Allusion Shallow Frame Face Fix Brackets

    Allusion Shallow Frame Face Fix Brackets size

    Or adjustable brackets for a Larger Frame

    Allusion Adjustable Face Fix Brackets

    Allusion Adjustable Face Fix Brackets size



    VALE Allusion Blinds can be bunched/stacked on either the left of the right of the window. This allows you to have the blind, when fully open, on the side that best suits your needs.

    Allusion Blind Left Stack Allusion Blind Right Stack

    Split stack is not recommended on this product due to the gap in the middle of the blind.

    Blind Installation Heights

    The 2014 changes to the child safety requirements of BS EN 13120:2009+A12014 place an obligation on all blind manufacturers to sell compliant products.

    If you do not know the installation height of the blind please enter 00 in the box and your blind will be manufactured in accordance with the Safety Regulation requirements.

    If you input an installation height (this is the height the mounting brackets will be installed above the floor level) then your blind may be manufactured with longer controls providing they confirm to the child safety legislation.

    For windows in unusual positions or installed extremely high, please contact us.

    Child Safe Installation Height Diagram

    If you are unsure please contact us on 01949 845399

    IMPORTANT INFORMATION

    When measuring for a top fix blind with a slimline head rail, there needs to be a recess depth of a minimum of 107mm. We recommend that you leave a gap of 15mm between the back of the vane and any obstruction like handles.

    When measuring for a top fix blind with a Fascia, there needs to be a recess depth of a minimum of 145mm. We recommend that you leave a gap of 15mm between the back of the vane and any obstruction like handles.

    Please note that when fitted there will be a gap between the recess wall and the end vane of around 83-88mm and when fitted outside the recess a gap of around 80-85mm.

    Allusion Blind Truck Spacing

    The distance between the top of the vanes to the recess ceiling will be around 62mm.

    Allusion Width Louvre Chart
