VALE 50mm Wooden Venetian Blind

Inside Recess

The recess is inside the window opening. Choose this option if you want to the blind to lie in the recess of the window.

Width: Measure the inside width of the window at the top middle and bottom. Use the narrowest width measurement always using a metal tape measure.

Height: Measure the height of the window at the left, centre and right. Use the shortest height measurement always using a metal tape measure.

We will deduct the manufacturers recommended tolerance off the width/drop of the blind to ensure the blind operates perfectly within the window recess.

Outside Recess/Exact

Outside Recess/Exact is the outside of the window opening, overlapping the window recess. Choose this option if you want the blind to overlap the window recess.

Width
To minimise light leakage it's recommended that the blind overlaps the window recess on the width by least 40mm each side (60mm in the case of vertical blinds).

Height
When measuring the height take into account the required space for the mounting bracket. A flat surface of a minimum 70mm above is required (50mm in the case of vertical blinds). The overlap at the bottom of the blind is a matter of personal choice but please take into account obstacles such as radiators.

If you are unsure please contact us on 01949 845399

VALE Wooden Venetian Blind Controls

VALE wood blinds come complete with a wooden wand to control the tilt of the slats and pull control to raise and lower the blind.

As standard these controls are on opposite sides of the blind - wand on the left and the cord on the right. However you can change this.

Manual operation with controls on opposite sides

Min width 300mm - Max width 2700mm

Min drop 250mm - Max drop 300mm

Max 5m²

Manual operation with controls on same side

Min width 450mm - Max width 2700mm

Min drop 250mm - Max drop 3000mm Battery operated Tilt & Lift Alternatively you can select a motorised option

Max 5m²

Alternatively you can select a motorised option

Battery Tilt & Lift operation with the Somfy Sonesse 30 Ultra motor with inbuilt rechargeable Lithium Batteries

Min width 750mm - Max width 2700mm

Min drop 250mm - Max drop 2200mm

Max 3m²

Battery Tilt ONLY operation with the Somfy Tilt 50 RTS motor and 12v Lithium Battery Pack

Min width 450mm - Max width 2700mm

Min drop 250mm - Max drop 2500mm

Max 5m²

Mains Electric operation with the Somfy Sonesse 40 RTS motor

Min width 6500 - Max width 2700mm

Min drop 250mm - Max drop 3000mm

Max 7m²

VALE 50mm Wooden Venetian Blind Remote Control

If you have selected a motorised blind you have the option of a hand held remote control or a wireless wall switch

	Situo 1 Variation RTS Pure Single Channel Remote The control wheel offers greater precision when tilting the slats of the blind Can have upto 8 items operating in unison on the single channel
	Situo 5 Variation RTS Pure Multi Channel Remote 4 Single channels and 1 Multi channel function Offers the ability to operate multiple blinds independently from 1 remote Each channel can have upto 8 items operating in unison
	Smoove 1 RTS Wireless Wall Switch Secure, single channel RTS (operates one blind or group of blinds simultaneously) Battery powered control unit that can be placed anywhere within range
	Smoove 4 RTS Wireless Wall Switch Secure, four channel RTS (operates up to 4 blinds or groups of blinds) Battery powered control unit that can be placed anywhere within range

If you are unsure please contact us on 01949 845399

VALE 50mm Wooden Venetian Blind Tapes

Blinds come complete with colour co-ordinating ladder cords. Motorised blinds are only available with ladder cords.

Alternatively you can select tapes on manually operated blinds - not available on motorised blinds.

VALE 50mm Wooden Venetian Blind Pelmet & Returns

As standard your blind will come complete with a colour co-ordinating pelmet

If you are fitting your blind outside of the recess you can add the mitred Pelmet Returns to the order

VALE 50mm Wooden Venetian Brackets

As standard your blind comes complete with Fac/Top fix Swivel Brackets

Alernatively you can select the Box End Brackets

If you are ordering Blinds to sit next to each other or in a bay you can select to have the slats/vanes lining up across several blinds. The Blinds must be installed at the same height and have the same drop.

The manufacturers will align the slats/vanes as closely as possible.

Please Note: The number of ladder cords or tapes on a blind varies according to the blind width. Even the smallest difference in size can result in a different number of ladder cords or tapes - If you need to know this please contact us

Blind Installation Heights

The 2014 changes to the child safety requirements of BS EN 13120:2009+A12014 place an obligation on all blind manufacturers to sell compliant products.

If you do not know the installation height of the blind please enter 00 in the box and your blind will be manufactured in accordance with the Safety Regulation requirements.

If you input an installation height (this is the height the mounting brackets will be installed above the floor level) then your blind may be manufactured with longer controls providing they confirm to the child safety legislation.

For windows in unusual positions or installed extremely high, please contact us.

If you are unsure please contact us on 01949 845399
