Perfect Fit Shutter Lite

Place your mouse over this image

Image gallery

22%OFF

Info
Installation Instructions (3)
Delivery

Specifications:

Elliptical Shaped Polysilk Vinyl 63mm Slats
Tilt Wand Control
Top and Bottom Rails - 50mm
Brackets suitable for UPVC windows

Alternate Options:

Unisplit Tilt Wand POA
Divider Rail POA
Multiple Panels on one glass POA

Size Restrictions:

Minimum Panel Width 247mm (Glass size 201mm)

Maximum Panel Width 800mm (Glass size 754mm)

Minimum Panel Height 275mm (Glass size 229mm)

Maximum Panel Height 2200mm (Glass size 2154mm)

NOTE: Measure the visible glass size, width and drop. The finished shutter will be approximately 46mm larger than the glass size ordered.

Delivery

For full details of our delivery times please
click here

Perfect Fit Shutter Lite

Cotton White

Order Code

10073

RRP from

£66.67

Our price from

£52.01

Perfect Fit Shutter Lite

Elliptical Shaped Polysilk Vinyl 63mm Slats
Easy to measure & install with no drilling or screwing
Moves with the window or door
Less framework than original shutters for improved view and light
Easily removed for cleaning and decorating
Waterproof - can be wiped clean
Can be fitted to inward opening windows and also French or patio doors

Suitable for UPVC windows and doors. Can be used on Wood or Aluminium windows and doors providing there is a curved bead and the bracket can be slotted behind the seal/gasket

NOTE: This product can ONLY be delivered to the UK Mainland and Northern Ireland

Price in GBP

RRP from

£66.67

Our price from

£52.01

Glass Size
Millimetres
Centimetres
Inches
Width
*
help text
Drop
*
help text

Notification Message close

Bead Depth

Tilt Bar Control

Window Handle Position

Window Handle Measurements

3 characters remaining.

Multiple Panels

Bead Depth

Your blind fits by clipping into the brackets that slot behind the gasket in your UPVC window.

To ensure you obtain the correct brackets you will need to measure your bead depth. To do this place a credit card over the corner of the window where the glass meets the gasket and take a note of the measurement from the glass to the edge of the card, this will be your bead depth and will determine the size of bracket required, see image below

Bead Depth Measuring diagram

Tilt Bar Location

The rotation of the shutter slats is controlled via a tilt bar that can be situated on the Left or the Right of the shutter.

Shutter left tilt wand Shutter right tilt wand

If you have a long window or door you many want to operate the top section independently from the bottom. If this is the case you can select the Unisplit Tilt Bar which allows you to have two controls on one shutter.

For more information on this please contact us on 01949 845399

Window Handle Location

If your window has a handle, the shutter will be manufactured with a handle rebate to accommodate. This will allow you to open and close your window with the shutter in place.

To allow the manufacturers to make the blind with the handle rebate in the correct place, you will need to let us know the handles location.

PFSL-Handle-on-the-Bottom PFSL-Handle-on-the-Left

PFSL-Handle-on-the-Right

Window Handle Measurement

If you have a window handle the shutter frame will be manufactured with a handle rebate to allow for the opening and closing of the window with the shutter in place.

Shutter handle rebate

When a handle rebate is ordered for a window with a handle on the side, the tilt bar control must be on the opposite side.

When measuring for a top or bottom handle rebate, please measure from the left side of the glass to the centre of the handle and use this measurement.

Top or Bottom handle rebate

When measuring a left or right side handle rebate, please measure from the bottom of the glass to the centre of the handle and use this meaurement.

Left or Right handle rebate

If you do not have a handle please put 00 in the box.

NOTE: The measurement for window handles can vary. Please do not assume they are central to the window.

Multiple Panels

It is possible to fit multiple shutter panels side by side within a single pane of glass, up to a maximum of six panels, ideal for larger windows. See examples below.

For this option, and a quotation, you will need to contact us via email. We will require the overall glass size and also how many panels are required. Our email address is info@valeblinds.com

The manufacturers will then divide the given glass size equally into the number of panels required.

Each extra panel will be supplied with a right-hand over left-hand astragal.

1 Shutter Variation 2 Shutter Variations 3 Shutter Variations
