VALE 127mm Vertical Blind

Inside Recess

The recess is inside the window opening. Choose this option if you want to the blind to lie in the recess of the window.

Width: Measure the inside width of the window at the top middle and bottom. Use the narrowest width measurement always using a metal tape measure.

Height: Measure the height of the window at the left, centre and right. Use the shortest height measurement always using a metal tape measure.

We will deduct the manufacturers recommended tolerance off the width/drop of the blind to ensure the blind operates perfectly within the window recess.

Outside Recess/Exact

Outside Recess/Exact is the outside of the window opening, overlapping the window recess. Choose this option if you want the blind to overlap the window recess.

Width
To minimise light leakage it's recommended that the blind overlaps the window recess on the width by least 40mm each side (60mm in the case of vertical blinds).

Height
When measuring the height take into account the required space for the mounting bracket. A flat surface of a minimum 70mm above is required (50mm in the case of vertical blinds). The overlap at the bottom of the blind is a matter of personal choice but please take into account obstacles such as radiators.



If you are unsure please contact us on 01949 845399

Vale 89mm & 127mm Vertical Blinds

Vale Vertical Blinds as standard have White Plastic Chain and Cord Controls. Alternatively you can select Nickel, Gold, Beige or Black plastic chains with colour co-ordinated Cords.

The Chain Control rotates the louvers and the Cord Control draws the louvers either open or closed.

EXAMPLE

As an alternative you have the option of the Wand that rotates and draws the louvers in one control.



Vale 89mm & 127mm Vertical Blinds

Vale Vertical Blinds as standard have the Slimline Vogue Head Rail in Ice White.

The Dimensions of this slimline head rail are 38.5mm wide and 27.34mm deep.

Options: Ice White, Piano Black, Champagne Gold, Espresso Brown & Brushed Aluminium

















Vale Vertical 89mm & 127mm Blinds

Vertical Blind stacking is where the louvres pull to when the blind is fully open.

Vale Vertical Blinds as standard are supplied with Right Hand Stacking and Right Hand Controls

Alternatively you can select Left Hand Stack and Controls or Split Stack with a choice of left or right hand controls

Vale 89mm & 127mm Vertical Blinds

Vale Vertical Blinds as standard have a White Plastic Stabilizing Bottom Chain.

Alternatively you can select Beige Plastic, Black Plastic or Nickel Effect Metal Chain.

However if you are selecting the 'Split Stack' option we would not recommend the Nickel Effect Metal Chain as this is to heavy for a Split Stack Blind.

Enclosed weights with no stabilizing chain are also available. These means there will not be any chain across the bottom of the blinds vanes.

Vale 89mm & 127mm Vertical Blinds

Vale Vertical Blinds as standard have Sprung Top Fix Brackets



Alternatively you can select Face Fix Brackets

Blind Installation Heights

The 2014 changes to the child safety requirements of BS EN 13120:2009+A12014 place an obligation on all blind manufacturers to sell compliant products.

If you do not know the installation height of the blind please enter 00 in the box and your blind will be manufactured in accordance with the Safety Regulation requirements.

If you input an installation height (this is the height the mounting brackets will be installed above the floor level) then your blind may be manufactured with longer controls providing they confirm to the child safety legislation.

For windows in unusual positions or installed extremely high, please contact us.

If you are unsure please contact us on 01949 845399
